Kathrein EAX 28 Professional CATV Splitter, 8 ports, 18 dB, Return Path Ready, 5–1000 MHz, 8 dB cascade output, Class A, Made in Germany
Product features
Kathrein EAX 28 Professional CATV Splitter – 8-tap 18 dB, 5–1000 MHz, Made in Germany
The Kathrein EAX 28 is a professional TAP-type splitter designed for CATV networks and coaxial distribution infrastructures for cable TV and cable internet (return-path ready). The device enables the uniform supply of multiple user points and the continuation of the main line via the cascade output, making it ideal for apartment blocks, hotels or commercial buildings.
Key features
- Professional product, Made in Germany
- TAP-type splitter: 8 side outputs
- TAP output attenuation: 18 dB
- Cascade (through) output: 8 dB
- Frequency range: 5 – 1000 MHz
- Compatible with CATV and coaxial internet networks (Return Path Ready)
- RF shielding: Class A – high protection against interference
- Standard 75 Ω F connectors
- Robust metal housing for stability and durability
Important – signal level and use of the amplifier
Multi-output splitters introduce attenuation specific to RF signal distribution. Depending on the installation, the total signal loss is influenced by the splitter’s attenuation, the length of the coaxial cable and intermediate components (connectors, TV sockets). If the signal level provided by the operator is not sufficient to compensate for these losses, reception problems or unstable operation may occur. In such situations, it is recommended to install a CATV amplifier upstream of the splitter.
Installation recommendations
- Recommended for professional CATV networks and communal distribution
- Enables the simultaneous distribution of cable TV and coaxial internet services
- For correct operation, unused ports must be terminated with 75 Ω terminating resistors
Technical specifications
- Model: Kathrein EAX 28
- Type: TAP-type CATV distributor
- Number of TAP outputs: 8
- TAP attenuation: 18 dB
- Main line attenuation: 8 dB
- Frequency range: 5–1000 MHz
- Impedance: 75 Ω
- Country of manufacture: Germany
